Server Specification

Server Specification

 Server  upto 5K Active users

  • CPU: 22 Cores or higher (Intel Xeon E5-2696 v4 / E5-2699 v4 recommended)
  • RAM: 32 GB or higher
  • Storage: 500 GB Enterprise NVMe SSD or Enterprise SSD
  • RAID: RAID 1 Recommended

Server : 5,000 – 10,000 Active Users

  • CPU: 22 Cores or higher (Intel Xeon E5-2696 v4 / E5-2699 v4 recommended)
  • RAM: 32 GB or higher
  • Storage: 500 GB Enterprise NVMe SSD or Enterprise SSD
  • RAID: RAID 1 Recommended

Server : 10,000 – 25,000 Active Users

  • CPU: 40 Cores or higher (Intel Xeon Gold 6138 or higher recommended)
  • RAM: 128 GB or higher
  • Storage: 1 TB Enterprise NVMe SSD or Enterprise SSD
  • RAID: RAID 1 or RAID 10 Recommended

Server : 25,000– 50,000 Active Users

  • CPU: 60 Cores or higher (Intel Xeon Gold series or higher recommended)
  • RAM: 256 GB or higher
  • System Storage: 4 TB Enterprise NVMe SSD or Enterprise SSD
  • Log Storage (1 Year): 72 TB Enterprise HDD/SSD (Mandatory)
  • Log Storage (2 Years): 144 TB Enterprise HDD/SSD (Mandatory)
  • RAID: RAID 10 with 4 Hot Spare Drives Recommended

Server : Above 50,000 Active Users

Please contact the IPACCT Technical Team for a customized server deployment tailored for large-scale ISP environments. Our enterprise deployment includes architecture planning for high availability (HA), load balancing, database optimization, high log retention, redundancy, disaster recovery, and full regulatory compliance to ensure maximum performance and reliability.

IPLOG Server : Up to 5,000 Users

  • CPU: 22 Cores or higher (Intel Xeon E5-2696 v4 / E5-2699 v4 recommended)
  • RAM: 32 GB or higher
  • System Storage: 2 TB Enterprise NVMe SSD or Enterprise SSD
  • Log Storage (1 Year): 8 TB Enterprise HDD/SSD (Mandatory)
  • Log Storage (2 Years): 16 TB Enterprise HDD/SSD (Mandatory)
  • RAID: RAID 1 with 2 Hot Spare Drives Recommended

IPLOG Server : 5,000 – 10,000 Users

  • CPU: 40 Cores or higher (Intel Xeon E5-2696 v4 / E5-2699 v4 recommended)
  • RAM: 64 GB or higher
  • System Storage: 2 TB Enterprise NVMe SSD or Enterprise SSD
  • Log Storage (1 Year): 16 TB Enterprise HDD/SSD (Mandatory)
  • Log Storage (2 Years): 32 TB Enterprise HDD/SSD (Mandatory)
  • RAID: RAID 1 with 2 Hot Spare Drives Recommended

IPLOG Server : 10,000 – 25,000 Users

  • CPU: 40 Cores or higher (Intel Xeon Gold 6138 recommended)
  • RAM: 128 GB or higher
  • System Storage: 4 TB Enterprise NVMe SSD or Enterprise SSD
  • Log Storage (1 Year): 36 TB Enterprise HDD/SSD (Mandatory)
  • Log Storage (2 Years): 72 TB Enterprise HDD/SSD (Mandatory)
  • RAID: RAID 10 with 2 Hot Spare Drives Recommended

IPLOG Server : 25,000 – 50,000 User

  • CPU: 60 Cores or higher (Intel Xeon Gold series or higher recommended)
  • RAM: 256 GB or higher
  • System Storage: 4 TB Enterprise NVMe SSD or Enterprise SSD
  • Log Storage (1 Year): 72 TB Enterprise HDD/SSD (Mandatory)
  • Log Storage (2 Years): 144 TB Enterprise HDD/SSD (Mandatory)
  • RAID: RAID 10 with 4 Hot Spare Drives Recommended

IPLOG Server : Above 50,000 User

Please contact the IPACCT Technical Team for a customized IPLOG deployment designed for large-scale ISP environments with high log retention, redundancy, and compliance requirements.

General Recommendations

  • Operating System: Ubuntu Server LTS (64-bit) or Debian Stable (64-bit)
  • Database: MariaDB (Latest Stable Version)
  • Filesystem: XFS or EXT4
  • Network: Minimum Dual 1 Gbps Ethernet (10 Gbps recommended for large deployments)
  • Power: Dual Redundant Power Supply (Recommended)
  • Backup: Automated Database and Configuration Backup
  • Time Synchronization: NTP Configuration Mandatory
  • Virtualization: VMware, Proxmox VE, Hyper-V, or KVM (Supported)
  • Monitoring: SNMP, Netdata, Zabbix, or Prometheus Recommended
  • High Availability: Recommended for deployments exceeding 25,000 active users.
